Lantronix SGX 5150 Command Reference

5: Commands and Levels
SGX™ 5150 IoT Device Gateway Command Reference 95
show history
Displays the last 20 commands entered during the current CLI session.
url <text>
Sets HTTP request URL following IP address or hostname.
username <text>
Sets the Username used to logon to HTTP server.
write
Stores the current configuration in permanent memory.
connection 2 (config-action-ftp_put-connection:eth0 link state change:2) level commands
clrscrn
Clears the screen.
default filename
Sets default FTP remote Filename.
default local port
Uses a random port number as the local port.
default port
Sets default Port number.
default protocol
Sets default FTP Protocol.
default username
Sets default Username.
exit
Exits to the next higher level.
filename <text>
Sets FTP remote Filename.
host <text>
Sets FTP server IP address or hostname to be connected to.
local port <number>
Sets a specific port for use as the local port. <number> = the number of the port to use.
no host
Clears FTP server IP address or hostname.
no password
Sets default Password.
password <text>
Sets the Password used to logon to FTP server.
port <number>
Sets the Port number which FTP server is listening to.
protocol ftp
Selects FTP Protocol.
protocol ftps
Selects FTPS Protocol.
show
Shows the current configuration.
show history
Displays the last 20 commands entered during the current CLI session.
username <text>
Sets the Username used to logon to FTP server.
write
Stores the current configuration in permanent memory.
cp functions (device-cp-functions) level commands
clrscrn
Clears the screen.
exit
Returns to the previous level.
reset to factory defaults
cp disable
Disables reset to factory defaults button function.
reset to factory defaults
cp enable
Enables reset to factory defaults button function.
show
Displays the current configuration.
show history
Displays the last 20 commands entered during the current CLI session.
wps pushbutton cp disa-
ble
Disables WPS PushButton button function.
wps pushbutton cp ena-
ble
Enables WPS PushButton button function.
write
Stores the current configuration in permanent memory.
credentials (ssl-credentials) level commands
clrscrn
Clears the screen.
create <credential name>
Create a new credential name
delete <credential name>
Delete existing credential by name
edit <credential name>
View or edit an existing credential
exit
Exits to the ssl level.
show
Show existing credential names

Lantronix SGX 5150 Specifications

General

Certification	FCC ICES-003:2012 RED 2014/53/EU, EMCD 2014/30/EU, EN 300 328 V1.9.1, EN 301 489-1 V1.9.2, EN301 489-17 V2.2.1, EN 301 893 V1.8.1, EN 62311: 2008 AS/NZS CISPR 22, AS/NZS 4268: A1: 2013, AS/NZS 2772.2VCCI EN 55022:2010, EN 55024:2010, EN 61000-3-2:A2 2009, EN 61000-3-3: 2008 UL 60950/CSA 22.2 No. 60950, IEC 60950 CE LVD 2014/35/EU
LED indicators	Yes
Power requirements	9 - 30 VDC
Power over Ethernet (PoE)	No
Power consumption (typical)	1.9 W
Storage temperature (T-T)	-40 - 85 °C
Operating temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	5 - 95 %
Security algorithms	802.1x RADIUS, AES, EAP-FAST, EAP-PEAP, EAP-TLS, EAP-TTLS, FIPS 140-2, MSCHAPv2, TKIP, WPA, WPA2, WPA2-PSK, WPS
Authentication method	RADIUS
Ethernet LAN (RJ-45) ports	1
Supported protocols	IPv4/IPv6, TCP, UDP, ICMP, ARP, Auto-IP, DNS, (S)FTP
Frequency band	2.4 / 5 GHz
Cabling technology	10/100BASE-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11d, IEEE 802.11g, IEEE 802.11h, IEEE 802.11i, IEEE 802.11n, IEEE 802.1x, IEEE 802.3, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s

Weight and Dimensions

Weight	350 g
Dimensions (WxDxH)	110 x 89 x 26 mm
