SPECIFICATIONS……..
Max Capacity:…………….500 lbs.
Motor Power:…………… 12 VDC
FIGURE 1 Contents of Carton A
Description Qty Part #
Hitch Adapter Plate……1 A C
Lifting Arm……………1 B
Guide Arms……………2 C B C
Pivot Tube……………..1 D
Platform Arms…………2 E
Outrigger Support …….1 F D
Outrigger Assemblies….2 G
E
E
F
G
Not Shown on this page (See Parts Diagram):
Hardware, CTN. #1
This box contains all the nuts, bolts and washers, and quick release pins and stabilizer clamp, outrigger assembly,
outriggers wrench and deck tie-downs.
Motorized cable module, CTN. #2
This box contains the motorized cable module, hex head cap screws, washers and nylon lock nuts required
to mount the module along with a hex key (allen wrench) for these bolts and cable set for connection to the battery.
Motor Controls, CTN. #3
This box contains the Pistol Grip Trigger, Limit Switch Assembly and screws, washers required to mount the Limit Switch
Assembly.
Deck Plate (On bottom of box)
SPECIFICATIONS ARE SUBJECT TO CHANGE
WITHOUT NOTICE
To Next Page
