- 7 -
7. Positioning the cotter pins
Measure the distance between the middle of
each of the connectors.
Deciding the cotter pin direction
If the measured distance is between:
• 25-40 cm (10-16 in.) ð Alt. A below.
• 40-50 cm (16-20 in.)ð Alt. B below.
7.
1
2
3
Alt. A
25 - 40 cm
40 - 50 cm
Alt. B
8. Choosing the correct hole
There are three holes in each arm. To choose
the hole which best suits your stroller, mount
the BuggyBoard as close as possible to your
stroller but also make sure your child can
stand comfortably.
Once decided, screw the cotter pin into your
chosen hole, tighten with a coin.
If the arms are too short to t your stroller,
there is an “Extender Kit” available as an
accessory, see g 13.
8.
English
