LaserLiner CompactPlane-Laser 3G Pro - Page 18

18
1
2
4
a
b
3
6
7
5
8
9
LED levelling
red: levelling off
green: levelling on
Laser line selection button;
Hand receiver mode on / off
LED hand receiver mode /
LED tilt function
Tilt function
Laser output windows
Battery compartment (bottom)
Slide switch
a ON
b OFF / Transport lock /
Slope mode
1/4" / 5/8" tripod threads
(bottom)
Battery status
6
7
8
9
1
2
3
4
5
