LaserLiner LaserRange-Master i3 User Manual

14
Calibration
The measuring device should be calibrated and tested on a regular
basis to ensure it is accurate and working properly. We recommend
the measuring device is calibrated every 1 - 2 years. If necessary, contact
your distributor or the UMAREX-LASERLINER service department.
Information on maintenance and care
Clean all components with a damp cloth and do not use cleaning agents,
scouring agents and solvents. Remove the battery(ies) before storing for
longer periods. Store the device in a clean and dry place.
Technical Data (Subject to technical changes without notice. 24W06)
Precision (typical)* ± 2 mm
Measurement range
(inside)**
0,3 m - 30 m
Laser class
2 / < 1 mW (EN 60825-1:2014/
A11:2021 / EN 50689-1:2021)
Laser wave length 635 nm
Automatic switch-off 30 sec laser / 3 min device
Power supply 2 x 1,5V LR03 (AAA)
Operating conditions
-10°C … 40°C, max. humidity 20 …
85% rH, no condensation, max. working
altitude 2000 m above sea level
Storage conditions
-20°C … 70°C,
max. humidity 80% rH
Dimensions (W x H x D) 40 x 110 x 24 mm
Weight 90 g (incl. batteries)
** at max. 5000 lux
* measuring distance up to 10 m with strongly reflective target surface
and at room temperature. The measurement deviation may increase
by ± 0.2 mm/m for weakly reflective target surfaces.
Error codes:
Err15:
Err16:
Err26:
Outside the measuring range
Received signal too weak
Value outside display range
EN

LaserLiner LaserRange-Master i3 Specifications

General

Wavelength	635 nm
Laser class	2
Measurement range	0.3 - 30 m
Measurement accuracy	± 0.002 m
Storage temperature (T-T)	-4 - 158 °F
Operating temperature (T-T)	-10 - 40 °C
Battery type	AAA
Auto power off	Yes
Battery voltage	1.5 V
Product color	Black

Weight and Dimensions

Weight	90 g
Dimensions (WxDxH)	40 x 24 x 110 mm
