SensoPilot Pro
ENGLISH8
1 Cover for charger socket
2 Charger socket
3 LED charge display
4 Socket for SensoPilot - remote
display connection cable OR 12/24V
battery cable
5 Laser beam receiver fields
6 LED laser height display (green)
7 LED laser height display (red)
8 LED laser height display (red)
9 Magnets for fixing to building
machine
10 ON / OFF switch
Precision selection
11 LED laser height display
12 Socket for SensoPilot - remote
display connection cable
13 Socket for 12/24V battery cable
14 Fixing bracket
15 Securing screw for fixing bracket
10
321
5
6
7
8
9
4
11 12 13
15 14
Remote display for
SensoPilot Pro
