lassele LFB-771PC - Page 13

13
1-3. PART LIST : LFB-1471PC
1-4.
NO.
CODE-No
Title
Subject
Q'TY
1
R2113-580
COMPRESSOR PULL OUT. A
CU-PIPE OD9.52*T0.7*1900
1
2
R2263-048
EVAPORATOR
F49
1
3
R370A-030
SHAFT TOP HINGE
SUM24L ￠15*45L
2
4
R3084-010
SUPPORT PCB
NYLON NO.66. M4*8
4
5
R3212-310
FRAME ASSY 49F
717.5*1408
1
6
R3214-282
TOP FRAME B/K
GI. T1.0*30*59.6
3
7
R3233-210
ASSY SHELF 49
609*580
6
R8429-012
ASSY SHELF CLIP
POM. WHT, 26SET
20
8
R315A-160
GRILL BRACKET
GI T1.0*10.6*102.7
2
9
R3314-241
SUPPORT FRONT B/K
STS304-2B. T1.0*80*34
2
10
R3323-230
CASTER 4"
4" MOVE
2
11
R3323-240
CASTER 4"
4" STOP
2
12
R3373-630
SHELF STANDARD L
AL. T1.2*930
6
13
R828A-065
ASSY HINGE TOP RH
STS304 T=4.0
2
14
R828A-055
ASSY HINGE TOP LF
STS304 T=4.0
15
R828A-022
ASSY HINGE BOTTOM RH
STS304 T=4.0
2
17
R828A-032
ASSY HINGE BOTTOM LF
STS304 T=4.0
18
R3393-530
LOW SHAFT RH
￠24*31
1
19
R3393-550
LOW SHAFT LF
￠24*31
1
20
R3734-030
DOOR LOCKING ASSY
ZDC. ZCR
2
21
R3813-351
COVER CAPACITOR
GI. T0.8*255.2*135
1
22
R3853-110
EVAPORATOR AIR GUIDE LF
AL WHITE,T0.5*162*247
1
23
R3853-090
EVAPORATOR AIR GUIDE RH
AL WHITE,T0.5*162*247
1
24
R3853-101
EVAPORATOR AIR GUIDE MID
AL WHITE,T0.5*161.8*243
1
25
R5133-160
MASCOT
POLYURT T1.5*205*38
1
26
R725B-250
PCB MAIN (115V CELSIUS)
FR1 BM 115V ℃ 냉동 BMR115C-01
1
27
R7203-020
DOOR SWITCH
WHT. SP201R-9D
2
28
R7204-070
POWER SWITCH
SL112A. 125V 15A
1
29
R748A-020
POWER RELAY
PANASONIC HE1AN-Q-DC-12V 30A
1
30
R7504-060
POWER TRANS
120V 60HZ. DT-1213
1
31
R8139-100
EVAPORATOR HOUSING ASSY
1
32
R8159-940
ASSY UNIT
F49. 115V. FRE
1
33
R8163-021
CROSS BAR SOLID ASSY
F49
1
34
R8272-490
DOOR ASSY LF (49)
R/F49
1
35
R8272-500
DOOR ASSY RH (49)
R/F49
1
36
R818A-300
BOTTOM GRILL ASSY
R/F49
1
37
R8199-070
EVAPORATOR DRAIN WATER-L ASSY
R/F49
1
38
R8279-090
CABI FOAM ASSY 49
F49
1
39
R8329-060
EVAPORATOR FAN MOTOR ASSY
115V 60HZ
2
40
R8359-510
ASSY CONTROL BOARD 49
R/F49
1
41
R7213-210
D-SENSOR
F23
1
42
R7259-070
EVAPORATOR THERMAL FUSE
F23
1
43
R7253-052
TEMP-THERMISTOR. FRE
MAX 72±5℃
1
