ECP5 PCI Express Board User’s Guide
Appendix A. Bill of Materials
PROJECT NAME: ECP5 PCI EXPRESS BOARD PAC NO: 305-PD-14-0XXX
CUSTOMER NAME: LATTICE DATE: 07-17-2014 REV:B
Item Reference Qty Part PCB Footprint Comments PART_NUMBER Manufacturer Description
1 CN1 1 Card 1 PCIe_EDGE_
FINGER
---
2 CN2 1 Card 2 PCIe_EDGE_
FINGER
---
3 CN3 1 PCI Express x4
Edge Finger Conn.
4X30X2MM PCI Express x4
Edge Finger
---
4 C5,C17,C141,
C147,C148,C159,
C160,C195,C198,
C199,C201,C204,
C214,C223,C224,
C226,C230
17 0.1uF C0603 - C1608X7R1E104
K080AA
TDK Corporation CAP CER .10UF 25V X7R 10% 0603
5 C6 1 0.01uF C0603 - C0603C103K5RA
CTU
Kemet CAP CAP CER 10000PF 50V 10% X7R 0603
6 C9,C55,C56,C65,
C78
5 330pF C0402 - C1005C0G1H331
J050BA
TDK Corporation CAP CER 330PF 50V 5% NP0 0402
7 C40,C41 2 18pF C0603 - C1608C0G1H180
J080AA
TDK Corporation CAP CER 18PF 50V C0G 5% 0603
8 C46,C69,C87,C97 4 10uF C1206 - C3216Y5V1E106
Z
TDK Corporation CAP CER 10UF 25V Y5V 1206
9 C47,C48,C62,
C74,C219
5 220nF C0402 - C1005X7R1C224
K050BC
TDK Corporation CAP CER 0.22UF 16V 10% X7R 0402
10 C49,C50,C61,C79 4 1nF C0402 - C1005C0G1E102
J050BA
TDK Corporation CAP CER 1000PF 25V 5% NP0 0402
11 C51,C52 2 100pF C0603 - C1608C0G1H101
J080AA
TDK Corporation CAP CER 100PF 50V 5% NP0 0603
12 C53,C54 2 10pF C0402 DNI C1005C0G1H100
D050BA
TDK Corporation CAP CER 10PF 50V NP0 0402
13 C58,C66,C75,
C82,C90,C174,
C175,C177,C181,
C326,C374,C391
12 1uF C0805 - C2012X5R1C105
K085AA
TDK Corporation CAP CER 1UF 16V 10% X5R 0805
14 C59,C67,C76,
C81,C172,C173,
C176,C240,C325,
C386
10 22uF_T C0805-T - F951A226MPAAQ
2
AVX CAP TANT 22UF 10V 20% 0805
15 C60,C68,C70,
C80,C94,C185,
C186,C187,C196,
C200,C205,C208,
C209,C210,C211,
C217,C218,C220,
C225,C227,C233,
C234,C237,C238,
C239,C243,C256,
C257,C275,C276,
C277,C278,C280,
C281,C282,C285,
C291,C292,C300,
C303,C305,C306,
C307,C311,C317,
C319,C322,C323,
C328,C330,C331,
C332,C334,C335,
C336,C337,C338,
C339,C340,C341,
C342,C343,C344,
C346,C347,C349,
C350,C351,C352,
C353,C354,C355,
C356,C357,C359,
C360,C362,C363,
C388
79 0.1uF C0402 - C1005X7R1C104
K050BC
TDK Corporation CAP CER 0.1UF 16V 10% X7R 0402
16 C64,C77 2 10pF C0402 - C1005C0G1H100
D050BA
TDK Corporation CAP CER 10PF 50V NP0 0402
17 C71 1 10uF_T C0805-T - TPSR106K006R1
500
AVX CAP TANT 10UF 6.3V 10% 0805
18 C88,C95 2 3.3uF C0805 - ECJ-2FB1A335K Panasonic - ECG CAP CER 3.3UF 10V 10% X5R 0805
