Laufen MEDA - Page 4

10 0-1 Nm
finally
tighten
screws
6
10 0-1 Nm
3 adjustment
screws for
fitting properly
vertical
alignement
8
3° max.
6
10 0-1 Nm
10 0-1 Nm
Loosen up
3 fastening
screws
slightly
6
If
Tube
is not
vertical
aligned
see next
steps
until 13
4
