28 INSTALLATION AND MAINTENANCE MANUAL 554515_A_PUB_DATE_1_FEB_2014.DOC
MACHINE kg / lb 80 / 180 100 / 230 120 / 275
A mm / inch
1495 / 58.86
1790 / 70.47 1855 / 73.03
B (1) mm / inch
2010 / 79.13
2060 / 81.10 2085 / 82.09
C mm / inch
1940 / 76.38 2005 / 78.94 2085 / 82.09
D mm / inch
1390 / 54.72 1688 / 66.46 1754 / 69.05
E (1) mm / inch
1133 / 44.60 1175 / 46.26 1200 / 47.24
F (1) mm / inch
778 / 30.63 820 / 32.28 775 / 30.51
G mm / inch
303 / 11.93 232 / 9.13 295 / 11.61
H mm / inch
168 / 6.61 232 / 9.13 247 / 9.72
I mm / inch
125 / 4.92 125 / 4.92 125 / 4.92
J mm / inch
125 / 4.92 125 / 4.92 125 / 4.92
K mm / inch
90 / 3.54 124 / 4.88 120 / 4.72
L mm / inch
100 / 3.93 110 / 4.33 148 / 5.83
M mm / inch
83 / 3.27 83 / 3.27 83 / 3.27
N mm / inch
210 / 8.26 210 / 8.26 210 / 8.26
O (1) mm / inch
1900 / 74.80 1518 / 59.76 1548 / 60.94
P (1) – for position 9 mm / inch
1787 / 70.35 1405 / 55.31 1435 / 56.50
Q (1) mm / inch
1983 / 78.07 1950 / 76.77 1980 / 77.95
R mm / inch
1460 / 57.48 1754 / 69.05 1820 / 71.65
S (1) mm / inch
282 / 11.10 268 / 10.55 243 / 9.57
T (1) mm / inch
437 / 17.20 419 / 16.50 394 / 15.51
U (1) mm / inch
662 / 26.06 696 / 27.40 722 / 28.43
V (1) mm / inch
735 / 28.93 768 / 30.24 795 / 31.30
W mm / inch
197 / 7.76 197 / 7.76 197 / 7.76
X mm / inch
380 / 14.96 527 / 20.75 562 / 22.13
Y mm / inch
665 / 26.18 650 / 25.59 757 / 29.80
Z – for position 6, 7,
10, 11, 12 mm / inch
1787 / 70.35
1836 / 72.28
1866 / 73.46
Table 3.5. – Machines 80-100-120 kg / 180-230-275 lb
(1) The dimensions of the machine with weighing system (on request) are higher. The height difference is in the
range of 74 - 79 mm / 2.91“ - 3.11“, based on the adjustment of the load sensor.
