Lawn Solutions TA21 - Page 13

Lawn Solutions Commercial Products, Inc. Page | 13
502-968-3188
TA21 Owner’s Manual
Item
Part Number
Description
1
LS0005a
Bearing 3/4"
LS0076
Bearing Flange
2
LS0320
Drive Tine ASM (Right Side)
LS0319
Drive Tine ASM (Left Side)
3
LS0321
Bronze Bushing 3/4"
4
LS0323
Upper Chain Cover (Right)
LS0322
Upper Chain Cover (Left)
5
LS0325
Float Tine ASM (Right)
LS0324
Float Tine ASM (Left)
6
LS0326
Bearing Spacer
7
LS0327
3/8" Rev Nut
8
LS0328
Bolt 3/8"-1.25" Grade 5
9
LS0329
Single Tine
10
LS0334
Grease Zerk
11
LS0330
Single Roller Chain (Full Length)
LS0331
Single Master Link
12
LS0333
Lower Chain Cover (Right)
LS0332
Lower Chain Cover (Left)
