lb pa Series - Channel Settings

CHANNEL Windows
The settings of the
individual channels
can be made in the
CHANNEL windows.
26
Input Window
Output Window
Input Gain + Level Meter
Delay up to 400 ms
per channel
Input mixer:
for each output
the inputs can be
mixed as desired
High Pass / Low Pass:
for each channel
various filters types
are available:
Parametric filters:
for each channel
10 filter types are
available:
Invert: rotates
the phase of the
channel by 180°
Output Gain +
Level Meter
Limiter
per channel
Compressor
per channel
Low Pass
High Pass
Low Pass 6dB
High Pass 6dB
Low Shelf
High Shelf
Bell
Notch
6dB
Butterworth 12dB
Butterworth 24dB
Bessel 12dB
Bessel 24dB
Linkwitz-Riley 12dB
Linkwitz-Riley 24dB
