LBC LRO-1G5 - Page 33

LRO-2__
1 1 150-138 Clip, Teflon
2 150-137 Clip, SS
3 30301-02 Microswitch
4 30308-05 30308-05 Air Switch
5 150-239 150-239 Hose
6 71700-03 71700-03 Hose Clamp
7 50803-04 Pin
8 150-130-1 150-130-1 Bracket
9 150-719-2 150-719-2 Fork Assembly
* 30200-68-A 30200-68-A Actuator Kit
* 150-1070 150-1070 Bearing Support
* Item not shown
LRO-2__
1 73000-06a 73000-06a Driven Gear
2,3,8 30200-56-1-A 30200-56-1-A Motor Kit
2a 40704-12 40704-12
Capacitor, 12mf
4
70200-11 70200-11 Flange Bushing
5
70200-12 70200-12 Washer
7 150-150-2 150-150-2 Spacer
9 50803-002 50803-002 Drive Collar
10 70200-13 70200-13 Bearing, Gear
11 70200-14 70200-14 Friction Disk
12 20601-04 20601-04 Snap Ring
13 50803-001 50803-001 Drive Collar
14 150-160 150-160 Teflon Spacer
15 150-161 150-161 Microswitch Brkt
16 30301-15 30301-15 Microswitch
17 150-158b 150-158b Spring Tab
18 150-159-1a 150-159-1a Pointer Assy
*
70200-15 Bushing, Split
70200-15
* Item not shown '
'
' '33
50803-04
LRO-1__
Item
Description
Illustrated Parts List (Part 3 of 7) /
' Liste illustrée des pièces / Ilustrado Lista de Piezas
Item
Description
150-138
Parts
LRO-1__
Parts
150-137
30301-02
Lifter
-Rotater
/
Soulevez
-
Rotation /
Rotar-Levantar
Rotater Detail
/
Rotateurs Détail
/
Detalle de los
Rotadores
