3 13/16
97mm
MAX.
2
51mm
MIN.
4 1/4
108mm
7/8
22mm
1 1/8
29mm
4 1/4
108mm
4 1/2
114mm
1 5/8
41mm
8 1/16
205mm
1 15/16
49mm
1 1/4
32mm
MIN.
1 1/2
38mm
MIN.
TOP JAMB MOUNTED ON 4030-18TJ ADAPTER PLATE
* Locate drop plate & shoe from centerline of
pivot or swing clear hinge pin when used.
LEFT HAND SHOWN, RIGHT HAND OPPOSITE
MAIN GAUCHE ILLUSTRÉE, MAIN DROITE CONTRAIRE
PUERTA DE MANO IZQUIERDA ILUSTRAR, MANO DERECHA LOAPUESTO
4030-18TJ
*
*
C
L
C
L
