CONNECTION:
-Connection via 6.3mm socket
-Connection via XLR connector
Pin3 (-)
Pin2 (+)
Pin1 ( )
(Linked to Pin1 manually, )
Pin1 ( )
Pin2 (+)
Pin3 (-)
Sleeve
Tip
+
Tip
Ring
Sleeve
+
-
Tip
Ring
Sleeve
+
Monocinch, asymmetric Stereocinch, symmetric Stereocinch, asymmetric
XLR, asymmetric XLR, symmetric
