Le Maitre DMX Interface - Page 2

Using The LSG/DMX Interface ........................................ Page 1
XLR Pin Assignments ................................................ Page 2
D.M.X. Addressing Example ...................................... Page 3
D.M.X. Binary Address Table ....................................... Page 4
Table of Contents
Specifications
Model : LSG/DMX Interface
Uses DMX 512 Protocol to switch on or off 115 Volt 10 Amp loads.
Size: 190.50mm x 190.50mm x 88.9mm high
7.50 x 7.50 x 3.50 high
Weight: 1.92 Kgs.
4.20 Lbs.
Power: Input :115 Volts A/C 12 Amps.
Power Output Switched: 10 Amps Maximum switched per auxilliary output
12 Amps Maximum total switched load.
