Leadtek Research Inc.
6
"!
$ <
Line Jack (Line)
for connecting to PSTN telephone line
Phone Jack (Phone)
for connecting to telephone
Input/Output Connector (I/O)
for connecting to I/O Box
Audio Input Connector (Audio In)
Audio Output Connector (Audio Out)
VISCA Connector (VISCA)
for PTZ Camera
Monitor Connector (Monitor)
for external VGA-Compatible monitor
VGA Connector (VGA)
for PC’s VGA output signal
Video Output Connector (Video Out)
for video signal output to TV
Video Intput Connector (Video In)
for video signal Input to TeleEye AE
Audio/Video Input Connector (A/V In)
Mode Switch (Mic/Line, PAL/NTSC)
DC Output (DC Out) for I/O Box
Power Input (Power In)
DC Out
Line
NTSC
Mic
PA L
Power In
Phone
Line
A/V In
Video In
Video Out
I/O
Audio In
Audio Out
VGA
Monitor
VISCA
1
2
3
4
6
7
8
9
10
11
12
13
5
for Audio In and TV mode
