- 12 -
• Detection of fault probes, maximum flexibility of managing and semplicity of
programming, checking of validity of the insert data during programming phase.
• Continuos storage of planned and reached values by each channel (limits and
historic highs).
• Dielectric isolation: 2.5 KV AC for 60”.
• Software configuration to control the environment temperature.
• Resolution 1° C.
• Working temperature of device from -20°C to 60°C.
• Max allowed dampness in the room 90% not condensing.
• Electrical connections with fast polarised connectors.
• Possibility of manual relays switch through menu test relays to simulate and
check the reliability of contact.
• Galvanically insulated output 4-20mA or 0-20mA (CT-4/20MA)
• Maximum impedance allowed for current output 500 Ohm (CT-4/20MA)
Range 4-20mA (-10°C 4mA / +200°C 20mA)
Transformation formula: lout = (T+10)/210*16 + 4 (current in mA, temperature in
°C)
Range 0-20mA (-10°C 0mA / +200°C 20mA)
Transformation formula: lout = (T+10)/210*20 (current in mA, temperature in
°C).
Transformation formula: lout = (T+10)/210*16 (current in mA, temperature in
°C).
• Technical manual in five languages (and more on request).
• Construction in accordance with rule EN 61000-6-2:2005 2014/30/EU.
• Input filter for power supply in accordance with rules .
• Tropicalization (optional).
ASSEMBLY
Perform a square hole measuring 91x91 mm in the panel board sheet.
Fasten the monitoring system trough the special hooks.
POWER SUPPLY
The device can be supplied with (24÷240) Volt AC/DC ±10% 50/60 Hz without
respect of polarity.
