TAB 2
- 20 -
REG
TYPE
DATA
RANGE
1
READ ONLY
Temperature channel 1
-1000 / +20000
2
READ ONLY
Temperature channel 2
-1000 / +20000
3
READ ONLY
Temperature channel 3
-1000 / +20000
4
READ ONLY
Temperature channel 4
-1000 / +20000
5
READ ONLY
Historical max temp. channel 1
-1000 / +20000
6
READ ONLY
Historical max temp. channel 2
-1000 / +20000
7
READ ONLY
Historical max temp. channel 3
-1000 / +20000
8
READ ONLY
Historical max temp. channel 4
-1000 / +20000
9
READ ONLY
Channel fault
0 / 0x000F
10
READ ONLY
Relays status
0 / 0x000F
REGISTRI MODBU S TCP/IP (TAB 2 )
MODBUS TCP/IP R EGISTERS (TAB 2 )
REGISTRES MODBU S TCP/IP (TAB 2 )
MODBUS TCP/IP-REGI STER (TAB 2 )
REGISTROS MODBU S TCP/IP (TAB 2)
20
READ WRITE
Function mode
0 / 4
21
READ WRITE
Channel enable
0 / 0x000F
22
READ WRITE
Fan status
0 / 0x000F
23
READ WRITE
Pre allarm channel 1
-1000 / +20000
24
READ WRITE
Pre allarm channel 2
-1000 / +20000
25
READ WRITE
Pre allarm channel 3
-1000 / +20000
26
READ WRITE
Pre allarm channel 4
-1000 / +20000
27
READ WRITE
Allarm channel 1
-1000 / +20000
28
READ WRITE
Allarm channel 2
-1000 / +20000
29
READ WRITE
Allarm channel 3
-1000 / +20000
30
READ WRITE
Allarm channel 4
-1000 / +20000
31
READ WRITE
Fan low level channel 1
-1000 / +20000
32
READ WRITE
Fan low level channel 2
-1000 / +20000
33
READ WRITE
Fan low level channel 3
-1000 / +20000
34
READ WRITE
Fan low level channel 4
-1000 / +20000
35
READ WRITE
Fan high level channel 1
-1000 / +20000
36
READ WRITE
Fan high level channel 2
-1000 / +20000
37
READ WRITE
Fan high level channel 3
-1000 / +20000
38
READ WRITE
Fan high level channel 4
-1000 / +20000
• Register 9 Status fault channel CH1 to CH4: bit 0 to bit 3
