RCbro
®
SPARROW 3-OSD
LefeiRC www.lefeirc.com/
*OSD menu item <GPS> can set whether to display the latitude and longitude information.
*The GPS icon will continue to flash when GPS is not connected or GPS is not fixed.
*‘>’ means to turn right, ‘<’ means to turn left, and the number after it indicates the specific
required turning angle.
*If the RC icon flashes, it means that the RC is failsafe or the receiver is disconnected. If the GPS
has been fixed at this time, it will automatically switch to the RTH.
➢ CONTROL OSD MENU
Set the gain, the YAW gain only works in ACRO .
Set the output directions of servos.
Set voltage/current offset.
In RTH, if the distance is beyond 3 times the circling
radius, the min flying altitude is <SAFE ALT>. If it is
higher than this altitude, it will slowly descend; after
approaching the HOME, the fly altitude is <RTH ALT>.
If the distance exceeds this radius, RTH will be triggered.
The flight mode corresponding to each position of the
mode channel(CH5/CH6).
The faster the speed, the smaller the required gain, and
the larger <VEL GAIN> should be.
Set AUX function(AXU3-6:CH1-4)
Set the output direction of the AUX.
Whether to display latitude and longitude.
MAVLINK:MAV1-57600, MAV2-115200,CRSF telemetry
Throttle differential ratio controlled by YAW.
Sticks control ratio in ACRO mode.
PWM:CH1-4 is PWM receiver channel.
AUX:CH1-4 is AUX3-6.
