13
At the rear of your MiST you will find a terminal plate housing jumpered
pairs of five-way binding posts. Connect the output of the rear channel
amplifier to the loudspeaker via the gold five-way binding posts provided.
Dual banana plugs or gold spade lugs are recommended means of
termination.
Be sure that you observe polarity when making the connections. The
positive (+) terminal (red) of the amplifier should be connected to the
positive terminal of the loudspeaker.
The negative (-) terminal (black) of the amplifier should be connected to
the negative terminal of the loudspeaker.
Bi-Amping MiST
Because MiST is a configurable design, it may be driven as a
progressively steered signal array. More specifically, one may wish to
drive one input with a side signal and the other input with a side rear
signal. This is useful in smaller spaces or in DSP controlled distribution.
