Legacy Phantom - Vertical Speaker Mounting Procedure

9
Vertical Mounting
- Find the center of one stud and mount the
provided bracket using the provided screws. Place
screws in the holes highlighted in red in figure 2.
- Lift the cabinet and slide the screws on the back of the
cabinet into the keyholes. This may take two people to
accomplish this task.
Speaker Installation
Figure 2
