Remove the folding lock
Open the hinge lock lever
as shown in the picture
Now you can fold up the frame
Make sure that the hinge is fully closed and that the locking lever is correctly aligned before securing it with the latch.
Properly adjusted, the lever closing force should be 4-8 KG (or 8.8-17.6 LB). Improper adjustment may damage the frame. If
you detect any clearances in any of the seal parts, please contact qualied personnel.
Release the folding lock by liing the double
safety tab beforehand
Open the hinge lock as shown in the picture
FOLDING THE BICYCLE_
