Lehman Renegade 2009 User Manual

2009-2013 FLH RENEGADE
UNPACKING THE KIT
PREPARING THE MOTORCYCLE
REMOVING HD SWINGARM
INSTALLING LEHMAN SWINGARM
TOP MOTOR MOUNT LINK
CARRIER/PULLEY
DIFFERENTIAL-LEFT HALF
DIFFERENTIAL-RIGHT HALF
BELT TENSIONING/TRACKING
BRAKE SYSTEMS
FRAME/SUSPENSION
EXHAUST
ELECTRICAL
BODY
REPLACEMENT PARTS
TORQUE SPECIFICATIONS
FINAL TRIKE INSPECTION
HARDWARE DESCRIPTION/BOLT BAG BREAKDOWN
*Notes before starting conversion
*For 2009+ FLHX (Street Glide) and FLTR (Road Glide) installations, the following parts will need
to be ordered from H-D for antenna and turn signal installation:
HD P/N
Description Qty.
76252-86 Base, antenna 1
76253-86 Reinforcement plate 1
76255-86 Gasket, base 1
11486 Grommet 1
68713-94A Lamp, rear signal 2
**Dakota Digital offers a hidden antenna kit as an alternative. Part # ANT-2000
*For 2010+ Models, the following parts are required.
HD P/N
Description Qty.
73108-96BK Pin Housing 1
73190-96 Terminal Pin 8
*For 2010+ FLTR Models, the following parts are required.
HD P/N
Description Qty.
65846-09 Muffler 1
LP1351 Exhaust Extension 1 (Lehman Part)
**ABS Models– Disabling the ABS light will also disable the cruise control light.
SECTION BREAKOUT
4
