2009-2013 FLH RENEGADE
The following instructions are a guide to preparing the motorcycle to accept the Lehman Trike Con-
version Kit. This will assist you in removing the necessary parts to install the kit. Refer to H-D ser-
vice manual for detailed procedures on motorcycle disassembly.
1. Locate motorcycle year, model and serial number, as well as Lehman serial number, located inside
body, on left-side of swingarm and on warranty registration form in owner’s manual.
2. Make sure motorcycle is standing straight up and handlebars are centered. Support motorcycle un-
der rear of transmission so it is straight up and down and handlebars are straight. The front forks or
handlebars should be anchored to hold bike.
NOTE: Use a small spirit level on rear wheel or disc brake to stand bike straight up. Any
movement of handlebars will move bike off level. Locate reference point on bike frame that
is level and check it frequently.
3. Remove seat and save mounting screw.
4. Disconnect battery.
CAUTION: Always disconnect negative battery cable first. If positive cable should contact a
grounded object while negative cable is installed, resulting sparks may cause an explosion.
5. Remove tour pack.
6. Raise motorcycle lift to working height.
7. Remove side stand mounting bolt and separate side stand from bracket.
8. Remove passenger footboards. Save boards and hardware for re-installation.
9. Remove side covers; they will be re-used.
10. Remove saddlebags (if equipped).
11. Remove mufflers and saddlebag mounts. Keep all muffler mounting hardware including rubber iso-
lators located in saddlebag mounts. These parts will be re-used.
12. Support bike on center stand.
13. Disconnect airlines from shocks and remove shocks. Stand shocks upright to prevent oil leaks.
Save air valve plate and discard original shock mounting bolts.
14. Remove rear fender and save turn signal lights.
15. Remove brake line from caliper and remove caliper.
16. Remove retaining clip from rear axle and remove axle nut with 36mm socket. Axle can now be re-
moved.
17. Remove rear wheel assembly.
18. Support transmission from below with jack and padded block.
PREPARING THE MOTORCYCLE
8
