12
Getting started with new equipment
GPS Equipment User Manual -2.0.0en
You cannot proceed from
here if no memory device is
available. Insert a PC-card
otherwise no GPS survey can be
carried out.
Measuring with the default configuration parameters, continued
Step 3 (optional):
Format your memory card
Before you start logging data you
may want to (re-)format your PC-card
or your internal memory.
This step is only necessary if a
completely new PC-card is used or
all existing data should be deleted !
Press 4 on the terminal or use the
Cursor key to highlight the line 4
Utilities, then press ENTER; alterna-
tively press F1 CONT.
(If only lines 1 to 3 are visible at this
stage press F4 SHOW first).
Then press 2 to get access to the
Format Memory Module panel, or
alternatively use the cursor key to
navigate to 2 Format Memory
Module and press ENTER; again
alternatively press F1 CONT.
The Battery Status icon at the right
side of the icon line shows from
which source the sensor is currently
powered. A and B indicate the
internal batteries, E an external
battery source. The symbol also
indicates the voltage level of the
currently used battery in 4 different
stages from "full" (fully black) to 2/3
to 1/3 and "almost flat" (white colour).
The Memory Status icon gives
several informations: whether
memory for logging data is available
or not. Options are either a PC-card
or internal memory. If a PC card is
available and configured for use then
at this stage an arrow indicates the
fact that it is safe to remove the PC-
card from the sensor. The little bar on
the right side indicates the available
memory on either the PC-card or the
internal memory.
