Leica BLK2GO PULSE User Manual

Care and Transport10
4 Care and Transport
Care and transport Carry the product in its original container to protect the product against shock and vibra-
tion and to protect the Dual Time-of-Flight LiDAR against scratches.
Periodically carry out test measurements, particularly after the product has been drop-
ped, stored for long periods or transported.
Field check
a
a
b
b
a Shield the BLK2GO PULSE from direct
sunlight and unfavourable weather.
b If the Dual Time-of-Flight LiDAR is
exposed to rain, scanning is not possible.
Ambient conditions

Leica BLK2GO PULSE Specifications

General

IMU	Yes
IP Rating	IP54
Laser Class	Laser Class 1
Scanning Rate	420, 000 points per second
Range	Up to 25 m
Camera	12 MP RGB camera
Operating Temperature	0°C to 40°C
Connectivity	Wi-Fi, USB-C
Software Compatibility	Leica Cyclone FIELD 360, Leica Cyclone REGISTER 360
