LEM 825 - Use and Maintenance Instructions; General Safety Warnings; Assembly and Operating Instructions; Parts List

PROFESSIONAL FRENCH FRY CUTTER
MODEL #825

# DESCRIPTION QTY # DESCRIPTION QTY
1 Wing Nut 3 11 Push Rod Bolt 2
2 ½" Cutting Plate with Frame 1 12 Push Rod 2
3 " Cutting Plate with Frame 1 13 Handle 1
4 " Push Plate 1 14 Guide Rod Nut 3
5 ½" Push Plate 1 15 Back Stand 1
6 Front Stand 1 16 Guide Rod 3
7 Push Plate Base 1 17 Base 1
8 Thumb Screw with Washer 2 18 Handle Bolt & Nut 2
9 Push Rod Mount 1 19
20
Suction Cup Feet (not shown)
Shaft
4
1
10 Push Rod Mount Screw 2
CARE:
• Thoroughly wash and rinse the unit with hot soapy water before use.
• For best results, DO NOT put unit in dishwasher.
CAUTION:
• KEEP OUT OF REACH OF CHILDREN. The blades are very sharp.
• Suction cups are not intended for use on pourous surfaces such as a wood- discoloration or possible marring may occur.
• When cutting brous vegetables such as yams, sweet potatoes and onions, use the large blade. Use a rm, quick pushing motion to
move the vegetables through the blades. Repeat as needed until the produce is through the blades.
• To produce the best strips, use fresh, rm fruits and vegetables such as carrots, cucumbers, zucchini, apples, yams, sweet potatoes,
onions, white, red and yellow potatoes.
USE:
1. To change the blade, remove the 3 Wing Nuts (#1) on the front of the Cutting Plate (#2 or #3) Front Stand (#6).
2. Place the alternate blade on the unit and replace the wing nuts.
3. To change the Push Plate (#4 or #5), remove the two Thumb Screws and Washers (#8) from the Push Plate Base (#7) and mount
the alternate plate in place. Replace screws.
4. The unit can be mounted to a sturdy surface of wall.
OPTIONAL: To install Suction Cup Feet Kit (#19) place the bolt of each suction cup through the holes in the feet of the cutter. Thread
the nylock nut onto each bolt tightly. Press firmly down on the French Fry Cutter to create suction between the surface and the
cutter. Suction cups work best on smooth, horizontal surfaces. To create more suction, a damp cloth can be swiped across the suction
cup prior to adhering. Check stability of the cutter prior to using.
NOTE: The suction cups are not meant to be used on a vertical surface. Use the suction cups for horizontal mounting purposes only.
7 8 9 10 11
12
20
17 16
11
14
15
18
3
2
1
4
5
6
CAUTION
Before using the appliance for the rst time please make sure to read carefully
and thoroughly through these operating instructions and the safety advice.
Familiarize yourself completely with the functions of the appliance.
1. Always ensure that the appliance is properly assembled and safely set up before use.
2. CAUTION: This appliance is not recommended for use near or by children or persons with certain disabilities. Set up and
store the appliance out of reach of children. Store the device in a secure and dry place out of reach of children. DO NOT
allow children to operate the appliance.
3. CAUTION: Exposed sharp metal blades! Use Extreme Caution when handling and cleaning metal blades. Do not touch
sharp edge of the blades. It is recommended that cut resistant gloves be worn when handling the blades.
4. Thoroughly hand-wash all removeable parts with warm, soapy water prior to use. Do not soak. NOT DISHWASHER SAFE .
5. The appliance is designed exclusively for domestic use and not for commercial purposes.
6. Use the appliance with the supplied accessories only. WARNING: The use of attachments not recommended or sold
by the manufacturer may cause injury, damage to personal property, and may void your warranty.
7. WARNING: DO NOT use while under the inuence of alcohol or drugs (prescription or non-prescription) as these may
impair user’s ability to properly assemble or safely operate the appliance.
8. The manufacturer declines any responsibility in the case of improper use of this product. Improper use of this product
voids the warranty.
9. Tie back loose hair and clothing and roll up long sleeves before operating the appliance. Remove ties, rings, watches,
bracelets or other jewelry before operating the slicer.
10. Use appliance with appropriately sized food. DO NOT attempt to process foods other than potatos or other rm
vegetables and fruits that have pits removed.
11.
SAVE THESE INSTRUCTIONS
LEM Products • West Chester, OH 45011 • 1-877-536-7763 • lemproducts.com
LEM Products • West Chester, OH 45011 • 1-877-536-7763 • lemproducts.com
2 3
ASSEMBLY & OPERATING INSTRUCTIONS
PARTS LIST
GENERAL WARNINGS AND SAFETY INFORMATION
