About Audacity - displays the version number and credits. If you compiled Audacity yourself, check
here to verify which optional modules were successfully compiled in.
TURNTABLE L-86
Type Belt drive, full manual
Drive motor DC motor
Speed 33rpm, 45rpm
Wow and flutter < 0.25% W(RMS)
Turntable platter 300 mm
Cartridge
Type Audio Technica AT-3600L
Stylus 0.6 mil
Optimum tracking force 3~4 grams
Output 2.5mV+-3db at 1KHz
Frequency response 0dB±3dB at 10KHz
Crosstalk 18dB(1 KHz) or more
Signal-to-noise ratio (S/N) 45dB above
GENERAL
ADAPTOR
input AC 100-240V~50/60Hz;
output DC 12V 0.3A
PRODUCT DC 12V, 0.3A
Audio output (Line Out) 100~300mV
Power consumption 3.6w
Dimension 537
×
435
×
361MM
Net weight 8.36KGS
5. Guarantee
Lenco offers service and warranty in accordance with the European law, which means that in case of
repairs (both during and after the warranty period) you should contact your local dealer.
Important note: It is not possible to send products that need repairs to Lenco directly.
Important note: If this unit is opened or accessed by a non-official service center in any way, the
warranty expires.
This device is not suitable for professional use. In case of professional use, all warranty obligations of
the manufacturer will be voided.
