LENCO LS-10 User Manual

7
Lenco
Turntable
LS-10
Type
Belt drive full manual
Drive Motor
DC motor
Speed
33 1/3 rpm, 45 rpm
Wow and flutter
<0.35%
Turntable platter
200mm
Cartridge
Type
N-10/Ceramic Cartridge 402-M208-015
Stylus
0.7 mil
Optimum Tracking force
4-6 grams
Output
160-380mV(HP-4005)
Frequency response
-28db(10KHz)
Crosstalk
10db(1KHz)
Signal-to-noise ratio(S/N)
40db
General
ADAPTOR
input AC100-240V~50/60Hz
output DC5V1000mA
PRODUCT
DC5v1000mA
Audio Output (Line Out)
200-500mv
Power Consumption
6W
Dimension
327x315x102mm
Weight
approx.2.2KGS LS-10WD
Weight
approx.2.2KGS LS-10BK
Power supply adaptor
Manufacturer: Shenzhen RiHuiDa Power Supply Co., Ltd.
Model number: RHD10W050100F
Use only the power supply listed in the user instructions

LENCO LS-10 Specifications

General

Type	Belt-drive audio turntable
Operation	Semi Automatic
Motor type	DC motor
Output level	380 mV
On/off switch	Yes
Product color	Black
Wow & flutter	0.35 %
Cartridge type	Ceramic stereo cartridge
Housing material	MDF
Turntable speeds	33, 45 RPM
Signal-to-Noise Ratio (SNR)	40 dB
Power supply type	AC
AC adapter frequency	50/60 Hz
AC adapter input voltage	100 - 240 V
AC adapter output current	1 A
AC adapter output voltage	5 V
Power consumption (standby)	0.5 W
Package depth	393 mm
Package width	420 mm
Package height	181 mm
Package weight	2550 g
Quantity per master (outer) case	2 pc(s)
Quantity per intermodal container (20ft)	740 pc(s)
Quantity per intermodal container (40ft, HC)	1530 pc(s)
Number of built-in speakers	2
Quantity	1
USB ports quantity	0
Headphone connectivity	3.5 mm
Tracking force range	4 - 6 g

Weight and Dimensions

Depth	315 mm
Width	327 mm
Height	102 mm
Weight	2160 g
Platter diameter	200 mm
