LENCO SCD-680 - Location of Controls and Unit Features; Control Panel and Ports Identification; Precautions for Use: Installation and Connection

Version: 1.0
22. Attentionshouldbedrawntotheenvironmentalaspectsofbatterydisposal;
23. Theuseofapparatusinmoderateclimates





LOCATIONOFCONTROL
1) USBsocket
2) Auxinsocket
3) 3.5mmheadphonejack
4) Cassettebutton
5) Handle
6) FMantenna
7) CDdooropen/close
8) LCDdisplay
9) Functionbutton
10) Stop /Enterbutton
11) Skip/Tuningdownbutton
12) Menu/Mem/clock‐adjustbutton
13) Timerbutton
14) Volumeup/downbutton
15) Cassettedoor

16) StandbyLED
17) On/Offbutton
18) Play/pause /Scanbutton
19) Skip/tuningupbutton
20) Pre/Folderup button
21) Info/Playmodebutton
22) ACsocket

Caution:
Usage of controls or adjustments or performance of procedures other than those specified herein may result in hazardous
radiationexposure.
Thisunitshouldnot
beadjustedorrepairedbyanyoneex ceptqualifiedservicepersonnel.

Important:
Since movementofthe cd mechanism and the sensitive circuitry maycause interferenceto the radio tuner nearby, switch this
unitoffwhileoperatingotherradiodevices.


DuetothecomplexityofMCUcontrol,pleaseun‐plugthemainpowersupplyoftheunitiffoundtheunithangup
duringoperation!
Thisisnotamalfunctionofthesystem!

Precautionsforuse
Installation
 Unpackallpartsandremoveprotectivematerial.
 Donotconnecttheunittothemainsbeforecheckingthemainvoltageandbeforeallotherconnectionshavebeenmade.
 Donotcoveranyventsandmakesurethatthereisaspaceofseveralcentimetersaroundtheunitfor
ventilation.
Connection
1. ConnecttheoneendofthedetachablepowercordtotheACsocket(22)andtheotherendtotheACoutlet.
2. Whenyoufirstplugtheunitintothemains,theunitwillgointostandbymode.TheStandbyLEDwilllightup
3. Turn on the unit
 by pressing “On/Standby” button (17).If the LCD display (8) is on with backlighting, it means the power
supplyisnormal.Nowthesystemisreadytoplaythemusic.

CLASS1LASER
PRODUCT
