Page 27
Integrated Control DIP Switch Settings
Conventional Thermostat (non-communicating)
Units are equipped with a two-stage, variable speed inte-
grated control. This control manages ignition timing, heat-
ing mode fan o delays and indoor blower speeds based
on selections made using the control dip switches and
jumpers. The control includes an internal watchguard fea-
ture which automatically resets the ignition control when
it has been locked out. After one hour of continuous ther-
mostat demand for heat, the watchguard will break and
remake thermostat demand to the furnace and automati-
cally reset the control to relight the furnace.
Note: All communicating settings are set at the communi-
cating thermostat. See thermostat installation instruction.
In a communication system all DIP switch and clippable
link settings are ignored. For conventional thermostats
proceed with DIP switch and clippable link settings as out-
lined in the following.
Heating Operation DIP Switch Settings
Switch 1 -- Thermostat Selection -- This unit may be
used with either a single-stage or two-stage thermostat.
The thermostat selection is made using a DIP switch
which must be properly positioned for the particular appli-
cation. The DIP switch is factory-positioned for use with a
two-stage thermostat. If a single-stage thermostat is to be
used, the DIP switch must be repositioned.
a. Select “OFF” for two-stage heating operation controlled by a
two-stage heating thermostat (factory setting);
b. Select “ON” for two-stage heating operation controlled by
a single-stage heating thermostat. This setting provides a
timed delay before second-stage heat is initiated.
Switch 2 -- Second Stage Delay (Used with Single-
Stage Thermostat Only) -- This switch is used to de-
termine the second stage on delay when a single-stage
thermostat is being used. The switch is factory-set in the
OFF position, which provides a 7-minute delay before
second-stage heat is initiated. If the switch is toggled to
the ON position, it will provide a 12-minute delay before
second-stage heat is initiated. This switch is only activat-
ed when the thermostat selector jumper is positioned for
Single stage thermostat use.
Switches 3 and 4 -- Blower-O Delay -- The blower-on
delay of 30 seconds is not adjustable. The blower-o delay
(time that the blower operates after the heating demand
has been satised) can be adjusted by moving switches 3
and 4 on the integrated control. The unit is shipped from
the factory with a blower-o delay of 90 seconds. The
blower o delay aects comfort and is adjustable to sat-
isfy individual applications. Adjust the blower o delay to
achieve a supply air temperature between 90° and 110°F
at the exact moment that the blower is de-energized. Lon-
ger o delay settings provide lower supply air tempera-
tures; shorter settings provide higher supply air tempera-
tures. TABLE 6 provides the blower o timings that will
result from dierent switch settings.
TABLE 6
Blower O Delay Switch Settings
Blower O Delay
Seconds
Switch 3 Switch 4
60 On O
90 (factory) O O
120 O On
180 On On
Indoor Blower Operation DIP Switch Settings
Switches 5 and 6 -- Cooling Mode Blower Speed -- The
unit is shipped from the factory with the dip switches po-
sitioned for high speed (4) indoor blower motor operation
during the cooling mode. TABLE 7 provides the cooling
mode blower speeds that will result from dierent switch
settings. Switches 5 and 6 set the blower cfm for second-
stage cool. The integrated control automatically ramps
down to 70% of the second-stage cfm for rst-stage cfm.
Refer to tables for corresponding cfm values. See Product
Specications for more detailed blower cfm tables.
TABLE 7
Cooling Mode Blower Speeds
Speed Switch 5 Switch 6
Low On On
Medium Low O On
Medium High On O
High (factory) O O
Switches 7 and 8 -- Cooling Blower Speed Adjustment
-- The unit is shipped from the factory with the dip switches
positioned for NORMAL (no) adjustment. The dip switches
may be positioned to adjust the blower speed by +10% or
-10% to better suit the application. TABLE 8 below pro-
vides blower speed adjustments that will result from dif-
ferent switch settings. Refer to tables for corresponding
cfm values. See Product Specications for more detailed
blower cfm tables.
TABLE 8
Cooling Blower Speed Adjustment
Adjustment Switch 7 Switch 8
+10% (approx) On O
Factory Default O O
-10% (approx) O On
Switches 9 and 10 -- Cooling Mode Blower Speed
Ramping -- Blower speed ramping may be used to en-
hance dehumidication performance. The switches are
factory set at option A which has the greatest eect on de-
humidication performance. TABLE 9 provides the cooling
mode blower speed ramping options that will result from
dierent switch settings. The cooling mode blower mode
blower speed ramping options are detailed on the next
page.
To Next Page
