BLOWER DATA
EL296DF090XV60C BLOWER PERFORMANCE (less lter)
BOTTOM RETURN AIR
0 through 0.8 in. w.g. (Heating) and 0 through 1.0 in. w.g. (Cooling) External Static Pressure Range
HEATING
1
Heating Speed
DIP Switch
Settings
First Stage Heating Speed - cfm Second Stage Heating Speed - cfm
+24% 1425 1895
+18% 1355 1825
+12% 1280 1740
+6% 1215 1660
Factory Default 1160 1575
–6% 1055 1455
–12% 1010 1365
–18% 950 1265
COOLING
1
Cooling Speed
DIP Switch
Settings
First Stage Cooling Speed - cfm Second Stage Cooling Speed - cfm
Low Medium-Low Medium-High
2
High Low Medium-Low Medium-High
2
High
+ 1115 1265 1400 1600 1600 1750 1970 2130
Factory Default 1005 1150 1275 1450 1450 1630 1810 1975
– 890 1065 1150 1270 1270 1450 1645 1810
1
Cooling and heating speeds are based on a combination of DIP switch settings on the furnace control. Refer to Installation Instructions for specic DIP Switch Settings.
2
Factory default setting.
NOTES - The e󰀨ect of static pressure is included in air volumes shown.
First stage HEAT is approximately 91% of the same second stage HEAT.
First stage COOL (two-stage air conditioning units only) is approximately 70% of the same second stage COOL speed position.
Continuous Fan Only speed is selectable at 28% and 38% of the selected second stage cooling speed - minimum 450 cfm.
Lennox iHarmony
®
Zoning System Applications - Minimum blower speed is 450 cfm.
EL296DF090XV60C BLOWER MOTOR WATTS (COOLING)
1
Cooling Speed
DIP Switch
Settings
Motor Watts @ Various External Static Pressures - in. wg.
First Stage Second Stage
0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0
+ Setting
Cooling
Speed
Low 79 108 144 162 207 242 262 293 323 275 299 366 399 449 483 532 584 605 644 680
Med-low 120 156 187 233 261 279 329 368 401 387 409 471 521 562 606 650 688 716 762 800
Med-High 155 202 235 293 317 369 407 453 502 547 577 622 667 744 795 835 872 910 950 963
High 268 299 366 399 449 483 532 584 605 780 775 811 898 942 994 1048 1071 1082 1080 1073
Factory Default
Cooling
Speed
Low 56 86 111 140 170 200 232 259 282 186 219 270 308 361 390 431 489 517 555 590
Med-low 93 118 152 195 223 254 283 306 344 278 304 365 420 450 510 544 592 640 665 698
Med-High 123 161 201 228 260 310 341 381 416 446 475 528 582 616 662 686 747 780 823 855
High 182 219 270 308 361 390 431 489 517 576 603 654 704 756 809 871 902 939 972 975
– Setting
Cooling
Speed
Low 48 69 101 120 152 175 201 218 249 118 155 181 232 259 299 340 376 402 438 476
Med-low 65 94 123 150 185 220 250 278 296 177 205 267 304 353 390 430 486 515 563 587
Med-High 93 118 152 195 223 254 283 306 344 301 322 392 439 468 531 568 599 647 678 721
High 116 155 181 232 259 299 340 376 402 446 475 528 582 616 662 686 747 780 823 855
