PARTS IDENTIFICATION
CONTROL BOX
(Includes integrated control,
transformer and door switch)
BAG ASSEMBLY
(shipping location)
VARIABLE SPEED MOTOR
(hidden)
OUTER
ACCESS
PANEL
COMBUSTION
AIR INDUCER
BURNER BOX ASSEMBLY
(includes sensor, rollout switches and ignitor)
GAS VALVE
BLOWER DECK
COLD END HEADER BOX
PRIMARY LIMIT
DuralokPlus
TM
HEAT EXCHANGER
ASSEMBLY
COMBUSTION AIR INDUCER
PRESSURE SWITCH
FIGURE 1
