EL296UHE Parts Identication
FIGURE 1
NOTE - This manual is the property of the homeowner
and must be left with the equipment user.
Notice to Homeowner
This furnace is equipped with safety devices that protect
you and your property. If one or more of these devices is
activated, furnace operation will stop. If your home is left
unattended for an extended period of time, equipment op-
eration must be checked periodically.
If this is not possible, the water supply to the house should be
shut off and the pipes should be drained. This will prevent prob-
lems associated with a NO HEAT condition (frozen pipes, etc.)
CAUTION
Before attempting to perform any service or maintenance,
turn the electrical power to unit OFF at disconnect switch.
DURALOK
TM
HEAT
EXCHANGER
ASSEMBLY
BURNERS
BLOWER
MOTOR
GAS VALVE
AND MANIFOLD
COMBUSTION AIR
INDUCER
FLUE
COLLAR
TOP CAP
INTEGRATED
CONTROL
PRESSURE SWITCH
ASSEMBLY
AIR INTAKE COLLAR
ACCESS PANEL
