HS29−072 & HS29−090 Control Box Arrangement
Figure 3
contactor
(K1)
capacitor
(C1)
minimum
run timer
(DL33)
outdoor fan relay
(K10)
latching relay
(K167)
ground lug
HS29−120 Control Box Arrangement
Figure 4
contactor (K1)
low ambient
thermostat
(S41)
capacitor
(C1,C2)
latching
relay (K167)
outdoor fan
relay 2 (K68)
outdoor fan
relay 1 (K10)
minimum run
timer (DL33)
ground
lug
