Lennox KCC Series User Manual

Page 46
EHA-7.5, 15, 22.5, 30, 45 & 60kW G, J VOLTAGE
KCC SERIES UNITS
Lennox Commercial
HEATING-ELETRIC
REV. 2
F42
2
7
1
6
5
3
8
9
4
K9−1
A
B
9
6
A
B
A
B
P2
L1 L2
L3
T1 T2
T3
L1 L2
L3
T1 T2
T3
4
7
1
S19
7
8
P7J7
S157
S158
S159
KEY COMPONENT
DL2
DELAY-ELECTRIC HEAT
F3 FUSE-ELECTRIC HEAT
F4 FUSE-UNIT
F42 FUSE-ELECTRIC HEAT 2
HE1 ELEMENT-ELECTRIC HEAT 1
HE2 ELEMENT-ELECTRIC HEAT 2
HE3 ELEMENT-ELECTRIC HEAT 3
HE4 ELEMENT-ELECTRIC HEAT 4
J7 JACK-ELECT HT SUB-BUS KIT
K9,-1,2
RELAY-HEAT
K15,-1
CONTACTOR-ELECTRIC HT 1
K16,-1
CONTACTOR-ELECTRIC HT 2
P2
PLUG-HEAT
P7 PLUG-ELECT HT SUB-BASE KIT
S15
SWITCH LIMIT, PRIMARY, ELECT HT
S19 THERMOSTAT-ELECTRIC HEAT LIMIT
S20
SWITCH-LIMIT, SECONDARY ELECT HT
S157
SWITCH LIMIT, SECONDARY ELECT HT 2
S158
SWITCH LIMIT, SECONDARY ELECT HT 3
S159
SWITCH LIMIT, SECONDARY ELECT HT 4
TB2TERMINAL STRIP-UNIT
TB3TERMINAL STRIP-ELECTRIC HEAT
