45
Installation and Maintenance
Service Manual
Above data is subject to change without notice.
No.
Description
Part Code
QtyLM009CI-100T432-1(Cold Plasma) LM012CI-100T432-1(Cold Plasma)
Product Code Y6760 Y6762
1
Front Panel 27230003811 20000300018 1
2
Display Board 30565260 30565260 1
3
Front Case Assy 00000200040 00000200045 1
4
Helicoid Tongue 26112508 26112436 1
5
Left Axile Bush 10512037 10512037 1
6
Rear Case assy 20162010 00000100093 1
7
Drainage Hose 0523001408 05230014 1
8
Ring of Bearing 26152022 26152022 1
9
O-Gasket sub-assy of Bearing 7651205102 7651205102 1
10
Evaporator Support 24212180 24212179 1
11
Evaporator Assy 0110010009501 01002976 1
12
Wall Mounting Frame 01252043 01252484 1
13
Cross Flow Fan 10352059 10352056 1
14
Fan Motor 150120874 1501214603 1
15
Connecting pipe clamp 2611216401 2611216401 1
16
Rubber Plug (Water Tray) 76712012 76712012 1
17
Stepping Motor 1521212901 1521210701 1
18
Crank 73012005 73012005 1
19
Electric Box Assy 10000202312 10000202314 1
20
Axile Bush 10542036 10542036 1
21 Terminal Board 42010276 42010276 1
22 Jumper 4202300116 4202300119 1
23 Main Board 30135965 30145023 1
24
Electric Box Cover Sub-Assy 01402065 01402065 1
25
Shield Cover of Electric Box Cover 01592150 01592150 1
26
Electric Box Cover 20112207 20112207 1
27
Power Cord 4002048718 4002048718 1
28
Connecting Cable 4002054010 4002054010 0
29
Connecting Cable / / /
30
Remote Controller 30510112_L35921 30510112_L35921 1
31 Cold Plasma Generator 1114001603 1114001603 1
To Next Page
