47
Installation and Maintenance
Service Manual
Above data is subject to change without notice.
No.
Description
Part Code
Qty
LM018CI-100T432-1(Cold Plasma)
Product Code Y6764
1 Remote Controller 30510112_L35921 /
2 Front Panel 27230003843 1
3 Display Board 30565260 1
4 Filter Sub-Assy 11122089 2
5 Decorative Board (Left) 20192662 1
6 Front Case 27230001983 1
7 Guide Louver 1051276501 1
8 Axile Bush 10542036 2
9 Air Louver 10512732 3
10 Helicoid tongue 26112512 1
11 Left Axile Bush 10512037 1
12 Rear Case assy 22202571 1
13 Rubber Plug (Water Tray) 76712012 1
14 O-Gasket sub-assy of Bearing 7651205102 1
15 Ring of Bearing 26152025 1
16 Evaporator Support 24212177 1
17 Evaporator Assy 01002686 1
18 Cross Flow Fan 10352060 1
19 Fan Motor 1501214502 1
20 Motor Press Plate 26112511 1
21 Wall Mounting Frame 01362026 1
22 Connecting pipe clamp 2611218801 1
23 Crank 73012005 1
24 Stepping Motor 1521240212 1
25 Drainage hose 05230014 1
26 Electric Box Assy 10000203305 1
27 Lower Shield of Electric Box 01592139 1
28 Electric Box 20112211 1
29 Jumper 4202300107 1
30 Main Board 30135988 1
31 Shield Cover of Electric Box 01592140 1
32 Electric Box Cover 20112209 1
33 Terminal Board 42010276 1
34 Decorative Board (Right) 20192662 1
35 Screw Cover 2425201726 3
36 Electric Box Cover2 20112210 1
37 Power Cord 4002048715 1
38 Connecting Cable 400205407 0
39 Connecting Cable / /
40 Cold Plasma Generator 1114001602 1
To Next Page
