49
Installation and Maintenance
Service Manual
Above data is subject to change without notice.
No.
Description
Part Code
QtyLM024CI-100T432-1(Cold Plasma)
Product Code Y6766
1
Front Panel Assy 20000300016 1
2
Filter Sub-Assy 11012007 2
3
Screw Cover 2425245301 3
4
Front Case Assy 00000200043 1
5
Air Louver(Manual) 10512737 3
6
Helicoid Tongue 26112513 1
7
Left Axile Bush 10512037 1
8
Rear Case assy 22202570 1
9
Rubber Plug (Water Tray) 76712012 1
10
Ring of Bearing 26152025 1
11
O-Gasket sub-assy of Bearing 7651205102 1
12
Cross Flow Fan 10352057 1
13
Evaporator Support 24212178 1
14
Evaporator Assy 01002988 1
15
Cold Plasma Generator 1114001602 1
16
Wall Mounting Frame 01252229 1
17
Motor Press Plate 26112515 1
18
Fan Motor 15012145 1
19
Connecting pipe clamp 26112514 1
20
Drainage Hose 0523001405 1
21 Stepping Motor 1521240212 1
22 Crank 73012005 1
23 Guide Louver 1051232001 1
24
Axile Bush 10542036 2
25
Electric Box 20112211 1
26
Terminal Board 42011233 1
27
Electric Box Cover2 20112210 1
28
Main Board 30135997 1
29
Display Board 30565260 1
30
Shield cover of Electric Box 01592140 1
31
Electric Box Cover 20112209 1
32
Jumper 4202300127 1
33
Lower Shield of Electric Box 01592139 1
34
Electric Box Assy 10000203671 1
35
Connecting Cable / /
36
Connecting Cable 4002053813 0
37
Temperature Sensor 3900031302 1
38
Remote Controller 30510112_L35921 1
