51
Installation and Maintenance
Service Manual
NO.
Description
Part Code
Qty
LM009CO-100T432-1
Product Code Y6761
1
Front grill 22413008 1
2
Front Panel 01533034P 1
3
Chassis Sub-assy 01700000048P 1
4
Compressor and ttings 00103978 1
5
Compressor Gasket 76710247 1
6
Inhalation Tube 03001000212 1
7
Discharge Tube 03500800465 1
8
Capillary Sub-Assy 03000600293 1
9
Valve 07100003 1
10
Valve 07100005 1
11
Big Handle 262334332 1
12
Valve Support 0170308901P 1
13
Right Side Plate Sub-Assy 01303183 1
14
Electric Box Assy
10000201510
1
15
Terminal Board 42011154 1
16
Capacitor CBB65 33000081 1
17
Capacitor CBB61 3301074710 1
18
Rear grill 1112320501 1
19
Condenser Assy 01100200302 1
20
Top Cover Sub-Assy 0125309902 1
21
Clapboard Sub-Assy 01233066 1
22
Motor Support 01703103 1
23 Fan Motor 150130676 1
24 Small Handle 26233100 1
25 Axial Flow Fan 10333427 1
Above data is subject to change without notice.
