53
Installation and Maintenance
Service Manual
NO.
Description
Part Code
Qty
LM012CO-100T432-1
Product Code Y6763
1
Front Grill 22413008 1
2
Front Panel 0153303204P 1
3
Chassis Sub-assy 0280330701P 1
4
Compressor and Fittings 00101374 1
5
Compressor Gasket 76710247 3
6
Overload Protector 00183123 1
7
Inhalation Tube 03533924 1
8
Discharge Tube 03500800456 1
9
Capillary Sub-assy 03000600288 1
10
Valve 07100003 1
11
Valve 07100006 1
12
Big Handle 262334332 1
13
Valve Support 01713041 1
14
Right Side Plate Assy 0130200404 1
15
Terminal Board 42011154 1
16
Capacitor CBB65 3300008102 1
17
Capacitor CBB61 3301074710 1
18
Electric Box Assy 10000201425 1
19
Rear Grill 11123205 1
20
Condenser Assy 01100200296 1
21
Top Cover Sub-Assy 01253061 1
22
Clapboard Sub-Assy 012334172 1
23
Motor Support 01703104 1
24 Fan Motor 150130676 1
25 Axial Flow Fan 10333427 1
Above data is subject to change without notice.
