55
Installation and Maintenance
Service Manual
Above data is subject to change without notice.
No
Description
Part Code
Qty
LM018CO-100T432-1
Product Code Y6765
1 Front Grill 22415001 1
2 Front Panel 01305015 1
3 Axial Flow Fan 10335261 1
4 Chassis Sub-assy 01203826P 1
5 Clapboard Sub-Assy 01233035 1
6 Compressor Gasket 76711065 3
7 Compressor and Fittings 00103986 1
8 Valve Support Sub-Assy 01715006 1
9 Cut off Valve 071302392 1
10 Cut off Valve 07130239 1
11 Valve Cover 22243003 1
12 Discharge Tube 03500800135 1
13 Handle 2623525404 1
14 Right Side Plate 01305095P 1
15 Capillary Sub-assy 03000600313 1
16 Inhalation Tube Sub-assy 03733986 1
17 Condenser Assy 01100200328 1
18 Motor Support Sub-Assy 0170309801 1
19 Rear grill 014730371 1
20 Coping 01255001 1
21 Fan Motor 15015057 1
22 Electric Box Assy 10000201648 1
23 Terminal Board 42011154 1
24 Capacitor CBB61 3301074704 1
25 Capacitor CBB65 3300008103 1
26 Left Handle 26235401 1
