Installation and Maintenance
Service Manual
No.
Description
Part Code
Qty
LM024CO-100T432-1
Product Code Y6767
1
Fan Motor 1501506102 1
2
Left Handle 26233053 1
3
Left Side Plate 01305093P 1
4
Supporting Board(Condenser) 01795010 1
5
Motor Support Sub-Assy 01705020 1
6
Coping 01255005P 3
7
Clapboard Sub-Assy 01235027 1
8
Condenser Assy 01100200331 1
9
Rear Grill 01473061 1
10
Capacitor CBB61 3301074705 1
11
Capacitor CBB65 3300008107 1
12
Electric Box Assy 10000201642 1
13
Terminal Board 42011113 1
14
Handle 26233053 1
15
Cut off Valve 07133157 1
16
Valve Cover 22245002 1
17
Cut off Valve 07133157 1
18
Valve Support Assy 01713098P 1
19
Right Side Plate 0130509402P 1
20
Capillary Sub-assy 03000600315 1
21
Discharge Tube 03001300232 1
22
Inhalation Tube Sub-Assy 03833935 1
23
Compressor and Fittings 00103327 1
24
Chassis Sub-assy 0280306302P 1
25
Axial Flow Fan 10335008 1
26
Front Panel 01535013P 1
27
Front Grill 22415002 1
Above data is subject to change without notice.
