4
Technical Information
Service Manual
Model
LM018CI-100T432-1
LM018CO-100T432-1
LM024CI-100T432-1
LM024CO-100T432-1
Product Code Y6764 Y6765 Y6766 Y6767
Power
Supply
Rated Voltage V~ 220-240 220-240
Rated Frequency Hz 50 50
Phases 1 1
Power Supply Mode Indoor Indoor
Cooling Capacity Btu/h 18000 24000
Heating Capacity Btu/h / /
Cooling Power Input W 1675 2164
Heating Power Input W / /
Cooling Power Current A 7.28 9.60
Heating Power Current A / /
Rated Input W 1950 2700
Rated Current A 8.48 10.64
Air Flow Volume(SH/H/M/L/SL) m
3
/h 850/780/680/540/- 1250/1100/960/820/-
Dehumidifying Volume L/h 1.8 2.0
EER (Btu/h)/W 10.70 11.09
COP (Btu/h)/W / /
SEER W/W / /
HSPF W/W / /
Application Area m
2
23-34 27-42
Indoor Unit
Model of indoor unit LM018CI-100T432-1 LM024CI-100T432-1
Indoor Unit Product Code Y6764 Y6766
Fan Type Cross-ow Cross-ow
Diameter Length(DXL) mm Ф106X706 Φ108X830
Fan Motor Cooling Speed(SH/H/M/L/SL) r/min 1350/1200/1050/900/- 1300/1150/1000/850/-
Fan Motor Heating Speed(SH/H/M/L/SL) r/min / /
Output of Fan Motor W 35 35
Fan Motor RLA A 0.35 0.35
Fan Motor Capacitor μF 2.5 3
Evaporator Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Pipe Diameter mm Ф7 Φ7
Row-n Gap mm 2-1.4 2-1.4
Coil Length (LXDXW) mm 715X25.4X304.8 845X25.4X381
Swing Motor Model MP35CJ MP35CJ
Output of Swing Motor W 2.5 2.5
Fuse A 3.15 3.15
Sound Pressure Level (SH/H/M/L/SL) dB (A) 48/43/40/36/- 48/45/40/37/-
Sound Power Level (SH/H/M/L/SL) dB (A) 58/53/50/46/- 58/55/50/47/-
Dimension (WXHXD) mm 970X300X224 1078X325X246
Dimension of Carton Box (LXWXH) mm 1038X380X305 1145X410X335
Dimension of Package (LXWXH) mm 1041X383X320 1148X413X350
Net Weight kg 13.5 16
Gross Weight kg 16.5 19.5
