Lennox LM012CI-100V432-1 User Manual

Parts Name
A5/B2/B4Panel:After energization, dual-8 nixie tube and power indicator blink once.
Under standby status, the power indicator is in red. After turning on the unit by remote
controller, power indicator is off. The dual-8 nixie tube displays current set temperature.
(Note: No operation indicator, heating indicator, cooling indicator and dry indictor for
models with A5 or B2 or B4 panels. Therefore, no mode indicator display during
operation status.)
Display content or position may be different from above graphics, please refer to actual
products.
Display
W R G
temp.
indicator
display
receiver
window
W R O
temp.
indicator
display
receiver
window
heating
indicator
temp.
indicator
cooling
indicator
power
indicator
receiver
window
drying
indicator
display
For some model:
For some model:
For some model:
For some model:
heating
indicator
temp.
indicator
cooling
indicator
power
indicator
receiver
window
drying
indicator
display
G
W
R
Power LED color indicator:
Green-status-ON.
Red-status-OFF.
Mode LED color indicator:
White-W-Cool Mode-
Red-R-Heat Mode-
Green-G-Dry Mode-
O
W
R
Power LED color indicator:
Green-status-ON.
Red-status-OFF.
Mode LED color indicator:
White-W-Cool Mode-
Red-R-Heat Mode-
Orange-O-Dry Mode-
(only for heating model)
(only for heating model)
