TABLE 8
Field Wiring Applications With Conventional Single Stage Thermostat
Thermostat
DIP Switch Settings and On-Board Links
Wiring Connections
DIP Switch 1
Thermostat
Heating
Stages
On Board Links
1 Heat / 1 Cool OFF
DO NOT CUT ANY
ON-BOARD LINKS
S1
SINGLE STAGE
T'STAT
FURNACE
TERM. STRIP
OUTDOOR
UNIT
Thermostat
DIP Switch Settings and On-Board Links
Wiring Connections
DIP Switch 1
Thermostat
Heating
Stages
On Board Links Must Be Cut To Select
System Options
Dual Fuel
Single Stage
Heat Pump
OFF
CUT ON-BOARD LINK
W951
HEAT
PUMP
FURNACE
TERM. STRIP
HEAT PUMP
Y
H
L
L
Y2
*
S1
SINGLE
STAGE
T'STAT
* Connect W1 to W1 ONLY if using defrost tempering kit 67M41
NOTE - Do NOT make a wire connection between the room thermostat L terminal and the L terminal of the integrated
control.
