132
Error Code:
E4
Description:
Indoor return air temperature sensor error
.
General Note:
Ifthevoltageislowerthan0.06Vorhigherthan4.94V
,theLEDwilldisplaytheerror
.
T
emperaturesensorerror
Checktheconnectionsbetweentempera
-
turesensorandPCB.
Aretheconnec
-
tionsgood?
Ye
s
No
No
Correcttheconnections
Checktheresistancevalueofthesensor
via
Appendix 1 and
Appendix 2.
Ye
s
Replaceindoororout
-
doorPCB.
Isitnormal?
No
Replacethesensor
.
