Locatingpartsonthesystemboard
Figure4“Locationsofthepartsandconnectorsonthesystemboard”onpage86showsthelocations
ofthepartsandconnectorsonthesystemboard.
Figure4.Locationsofthepartsandconnectorsonthesystemboard
1Integratedcameracableconnector
9SATAconnector
2Memoryslots(2)
10Microprocessorfanconnector
3Battery
11SATAconnector
4Cardreaderconnector12Opticaldrivepowerconnector/Harddiskdrivepower
connector
5Internalspeakercableconnector13Inverterconnector
6Controlbuttonconnector
14Powersupplyconnector
7LCDpanelconnector
15Microprocessor
8WI-FIconnector
86ThinkCentreEdgeHardwareMaintenanceManual
