8. Pivot the tool in the direction as shown to release the keyboard 1 . Push the keyboard in the direction as
shown by arrows
2 to release the latches from the keyboard bezel.
9. Pivot the keyboard slightly upward as shown by arrow 1 . Then turn the keyboard over as shown by
arrow
2 .
80 E580 User Guide
